| Crimp Contact Name : |
|
Operator : |
|
| Crimp Contact ID : |
|
770150-1 |
|
Wire Combination : |
|
| Tool Number : |
|
AWG No. |
|
AWG 18 |
| Manufacturer : |
|
Tyco |
|
Original Wire Number : |
16 |
|
|
|
Target Crimp Height : |
|
1.5500 +/- 0.0500 |
|
Crimp Height : |
|
1.574 |
|
Target Crimp Width : |
|
2.4000 +/- 0.0500 |
|
Crimp Width : |
|
2.4118 |
|
Conductor Cross Section : |
|
0.8567 |
|
Crimp Compression : |
|
-4.09% |
|
|
Target Crimp Height : |
|
1.5000 +/- 0.0500 |
|
Crimp Height : |
|
1.5105 |
|
Target Crimp Width : |
|
2.4000 +/- 0.0500 |
|
Crimp Width : |
|
2.3969 |
|
Conductor Cross Section : |
|
0.7917 |
|
Crimp Compression : |
|
3.81% |
|
|
Target Crimp Height : |
|
1.4500 +/- 0.0500 |
|
Crimp Height : |
|
1.459 |
|
Target Crimp Width : |
|
2.4000 +/- 0.0500 |
|
Crimp Width : |
|
2.4068 |
|
Conductor Cross Section : |
|
0.7488 |
|
Crimp Compression : |
|
9.02% |
|
|
Target Crimp Height : |
|
1.4000 +/- 0.0500 |
|
Crimp Height : |
|
1.4193 |
|
Target Crimp Width : |
|
2.4000 +/- 0.0000 |
|
Crimp Width : |
|
2.4168 |
|
Conductor Cross Section : |
|
0.6872 |
|
Crimp Compression : |
|
16.51% |
|
|
Target Crimp Height : |
|
1.3500 +/- 0.0500 |
|
Crimp Height : |
|
1.3538 |
|
Target Crimp Width : |
|
2.4000 +/- 0.0500 |
|
Crimp Width : |
|
2.3969 |
|
Conductor Cross Section : |
|
0.6568 |
|
Crimp Compression : |
|
20.19% |
|
|
|
|
|
|
|
|
